ZiLOG eZ80 User Manual

eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
60
BIT b,s
Z ←
~s[b]
(HL) CB 46–7E X*1 X 0—
(IX/Y+d) DD/FD CB dd
46–7E
r CB 40–7F
CALL cc,Mmn
if cc {
(SP) ←
PC
PC ← Mmn
}
C4–FC ——————
CALL Mmn
(SP) ←
PC
PC ← Mmn
CD ——————
CCF
C
← ~C
3F —— * — 0 *
CP A,s
A – s
(HL) BE *** V 1*
ir DD/FD BC–BD
(IX/Y+d) DD/FD BE dd
n FE
r B8–BF
CPD
A–(HL)
HL ←
HL – 1
BC ←
BC – 1
ED A9 ****1—
CPDR
repeat {
A–(HL)
HL ←
HL – 1
BC ←
BC – 1
} while (~Z and BC
≠ 0)
ED B9 ****1—
Table 37. Instruction Summary (Continued)
Instruction and Operation
Address Mode
Opcode(s)
(Hex)
Flags Affected
Dest Source S Z H P/V N C
Note: *This flag value is a function of the result of the affected operation.
— = No Change.
0 = Set to 0.
1 = Set to 1.
V = Set to 1 if overflow occurs.
X = Undetermined.
P = Set to the parity of the result (0 if odd parity, 1 if even parity).
IEF2 = The value of Interrupt Enable Flag 2.
