ZiLOG eZ80 User Manual

eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
64
INDRX
repeat {
(HL)
← ( {00h, DE[15:0]})
BC
← BC – 1
HL
← HL – 1
} while BC
≠ 0
ED CA —1—— *—
INI
(HL)
← ( {00h, BC[15:0]})
B
← B – 1
HL
← HL+1
ED A2 —*—— *—
INI2
(HL)
← ( {00h, BC[15:0]})
B
← B – 1
C
← C+1
HL
← HL+1
ED 84 —*—— *—
INI2R
repeat {
(HL)
← ( {00h, DE[15:0]})
BC
← BC – 1
DE
← DE+1
HL
← HL+1
} while BC
≠ 0
ED 94 —1—— *—
INIM
(HL)
← ( {0000h, C})
B
← B – 1
C
← C+1
HL
← HL+1
ED 82 X*X X *X
Table 37. Instruction Summary (Continued)
Instruction and Operation
Address Mode
Opcode(s)
(Hex)
Flags Affected
Dest Source S Z H P/V N C
Note: *This flag value is a function of the result of the affected operation.
— = No Change.
0 = Set to 0.
1 = Set to 1.
V = Set to 1 if overflow occurs.
X = Undetermined.
P = Set to the parity of the result (0 if odd parity, 1 if even parity).
IEF2 = The value of Interrupt Enable Flag 2.
