IND2
(HL)
←
({00h, BC[15:0]})
B
←
B – 1
C
←
C – 1
HL
←
HL – 1
ED 8C —*—— *—
IND2R
repeat {
(HL)
←
({00h, DE[15:0]})
BC
←
BC – 1
DE
←
DE – 1
HL
←
HL – 1
} while BC
≠
0
ED 9C —1—— *—
INDM
(HL)
←
({0000h, C})
B
←
B – 1
C
←
C – 1
HL
←
HL – 1
ED 8A X*X X *X
INDMR
repeat {
(HL)
←
({
0000h
, C})
B
←
B – 1
C
←
C – 1
HL
←
HL – 1
} while B
≠
0
ED 9A —1—— *—
INDR
repeat {
(HL)
←
(
{00h, BC[15:0]})
B
←
B – 1
HL
←
HL – 1
} while B
≠
0
ED BA —1—— *—
Table 37. Instruction Summary (Continued)
Instruction and Operation
Address Mode
Opcode(s)
(Hex)
Flags Affected
Dest Source S Z H P/V N C
Note: *This flag value is a function of the result of the affected operation.
— = No Change.
0 = Set to 0.
1 = Set to 1.
V = Set to 1 if overflow occurs.
X = Undetermined.
P = Set to the parity of the result (0 if odd parity, 1 if even parity).
IEF2 = The value of Interrupt Enable Flag 2.
