eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
68
LDD
(DE)
←
(HL)
DE
←
DE
–
1
HL
←
HL
–
1
BC
←
BC
–
1
ED A8 ——0*0—
LDDR
repeat {
(DE)
←
(HL)
DE
←
DE
–
1
HL
←
HL
–
1
BC
←
BC
–
1
} while BC
≠
0
ED B8 ——0*0—
LDI
(DE)
←
(HL)
DE
←
DE+1
HL
←
HL+1
BC
←
BC
–
1
ED A0 ——0*0—
LDIR
repeat {
(DE)
←
(HL)
DE
←
DE+1
HL
←
HL+1
BC
←
BC
–
1
} while BC
≠
0
ED B0 ——0*0—
LEA IX/Y, IX+d
IX/Y
←
IX+d
IX+d ED 32-55 ——————
LEA IX/Y, IY+d
IX/Y
←
IY+d
IY+d ED 33-54 ——————
LEA rr, IX+d
rr
←
IX+d
IX+d ED 02-22 ——————
LEA rr, IY+d
rr
←
IY+d
IY+d ED 03-23 ——————
Table 37. Instruction Summary (Continued)
Instruction and Operation
Address Mode
Opcode(s)
(Hex)
Flags Affected
Dest Source S Z H P/V N C
Note: *This flag value is a function of the result of the affected operation.
— = No Change.
0 = Set to 0.
1 = Set to 1.
V = Set to 1 if overflow occurs.
X = Undetermined.
P = Set to the parity of the result (0 if odd parity, 1 if even parity).
IEF2 = The value of Interrupt Enable Flag 2.
