ZiLOG eZ80 User Manual

eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
71
OTIR
repeat {
({00h, BC[15:0]})
← (HL)
B ← B – 1
HL ← HL+1
} while B ≠ 0
ED B3 —1—— *—
OTIRX
repeat {
({00h, DE[15:0]})
← (HL)
BC ← BC – 1
HL ← HL + 1
} while BC ≠ 0
ED C3 —1—— *—
OUT (BC),r also OUT (C),r
({00h, BC[15:0]})
← r
ED 41–79 ——————
OUT (n),A
({00h, A, n})
← A
D3 ——————
OUT0 (n),r
({0000h, n})
← r
ED 01–39 ——————
OUTD
({00h, BC[15:0]})
← (HL)
B
← B – 1
HL
← HL – 1
ED AB —*—— *—
OUTD2
({00h, BC[15:0]})
← (HL)
B
← B – 1
C
← C – 1
HL
← HL – 1
ED AC —*—— *—
OUTI
({00h, BC[15:0]})
← (HL)
B
← B – 1
HL
← HL+1
ED A3 —*—— *—
Table 37. Instruction Summary (Continued)
Instruction and Operation
Address Mode
Opcode(s)
(Hex)
Flags Affected
Dest Source S Z H P/V N C
Note: *This flag value is a function of the result of the affected operation.
— = No Change.
0 = Set to 0.
1 = Set to 1.
V = Set to 1 if overflow occurs.
X = Undetermined.
P = Set to the parity of the result (0 if odd parity, 1 if even parity).
IEF2 = The value of Interrupt Enable Flag 2.
