ZiLOG eZ80 User Manual

eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
72
OUTI2
({00h, BC[15:0]})
← (HL)
B
← B – 1
C
← C+1
HL
← HL+1
ED A4 —*—— *—
PEA IX+d
if ADL mode {
(SPL)
← IX+ d
SPL
← SPL – 3
}
else Z80 mode {
SPS
← IX+ d
SPS
← SPS – 2
}
ED 65 ——————
PEA IY+d
if ADL mode {
(SPL)
← IY+ d
SPL
← SPL – 3
}
else Z80 mode {
SPS
← IY+ d
SPS
← SPS – 2
}
ED 66 ——————
POP ss
if ADL mode{
ss
← (SPL)
SPL
← SPL+3
}
else Z80 mode {
ss
← { MBASE, SPS}
SPS
← SPS+2
}
AF F1 F
← (SPL) or (SPS)
IX/Y DD/FD E1 ——————
rr C1-E1 ——————
Table 37. Instruction Summary (Continued)
Instruction and Operation
Address Mode
Opcode(s)
(Hex)
Flags Affected
Dest Source S Z H P/V N C
Note: *This flag value is a function of the result of the affected operation.
— = No Change.
0 = Set to 0.
1 = Set to 1.
V = Set to 1 if overflow occurs.
X = Undetermined.
P = Set to the parity of the result (0 if odd parity, 1 if even parity).
IEF2 = The value of Interrupt Enable Flag 2.
