ZiLOG eZ80 User Manual

eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
73
PUSH ss
if ADL mode {
(SPL)
← ss
SPL
← SPL – 3
}
else Z80 mode{
SPS
← ss
SPS
← SPS – 2
}
AF F5 ——————
IX/Y DD/FD E5
rr C5-E5
RES b,s
s[b]
← 0
(HL) CB 86-BE ——————
(IX/Y+d) DD/FD CB dd
86-BE
r CB 80-BF
RET
PC ←
(SP)
C9 ——————
RET cc
if cc {PC ←
(SP)}
C0-F8 ——————
RETI
PC ←
(SP)
ED 4D ——————
RETN
Same as RET, with addition of
IEF1 ←
IEF2
ED 45 ——————
RL s (HL) CB 16 **0 P 0*
(IX/Y+d) DD/FD CB dd
16
r CB 10-17
RLA A 17 —— 0 — 0 *
Table 37. Instruction Summary (Continued)
Instruction and Operation
Address Mode
Opcode(s)
(Hex)
Flags Affected
Dest Source S Z H P/V N C
Note: *This flag value is a function of the result of the affected operation.
— = No Change.
0 = Set to 0.
1 = Set to 1.
V = Set to 1 if overflow occurs.
X = Undetermined.
P = Set to the parity of the result (0 if odd parity, 1 if even parity).
IEF2 = The value of Interrupt Enable Flag 2.

ZiLOG eZ80 Specifications

General

CPU Family	eZ80
Core	eZ80
Architecture	8-bit
Clock Speed	up to 50 MHz
Addressable Memory	16 MB
Register Size	8-bit
Serial Interfaces	UART, SPI, I2C
Operating Temperature	-40°C to +85°C
Instruction Set	Z80 compatible
On-Chip Flash Memory	Up to 256 KB
On-Chip SRAM	Up to 16 KB
Operating Voltage	3.0V to 3.6V
Package Types	LQFP, QFP
Timers	Multiple timers/counters
Power Consumption	Low power

Summary

Introduction

Architectural Overview

Processor Description

Pipeline Description

Memory Modes

Z80 MEMORY Mode

Describes Z80-compatible addressing with 16-bit registers and default operating mode on reset.

ADL MEMORY Mode

Explains ADL mode utilizing 16MB linear addressing and 24-bit registers.

Registers and Bit Flags

eZ80® CPU Working Registers

Details the two banks of working registers: main and alternate.

eZ80® CPU Control Register Definitions

Lists registers controlling CPU operation: I, IX, IY, MBASE.

eZ80® CPU Control Bits

eZ80® CPU Registers in Z80 Mode

Details CPU registers and bit flags when operating in Z80 mode.

Memory Mode Switching

ADL Mode and Z80 Mode

Opcode Suffixes for Memory Mode Control

Mixed-Memory Mode Applications

MIXED MEMORY Mode Guidelines

Interrupts

Interrupt Enable Flags (IEF1 and IEF2)

Interrupts in Mixed Memory Mode Applications

eZ80® CPU Response to a Nonmaskable Interrupt

Details how the CPU accepts and responds to nonmaskable interrupts (NMIs).

eZ80® CPU Response to a Maskable Interrupt

Describes how the CPU responds to maskable interrupts using Interrupt Modes 0, 1, and 2.

I/O Space

Addressing Modes

Register Indirect Addressing

CPU Instruction Set

eZ80® CPU Assembly Language Programming Introduction

eZ80® CPU Instruction Notations
