ZiLOG eZ80 User Manual

eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
74
RLC s (HL) CB 06 **0 P 0*
(IX/Y+d) DD/FD CB dd
06
r CB 00-07
RLCA A 07 —— 0 — 0 *
RLD
A[3:0] ←
(HL)[7:4]
(HL)[7:4] ←
( HL)[3:0]
(HL)[3:0] ←
A[3:0]
ED 6F **0 P 0—
RR s (HL) CB 1E **0 P 0*
(IX/Y+d) DD/FD CB dd
1E
r CB 18-1F
RRA A 1F —— 0 — 0 *
Table 37. Instruction Summary (Continued)
Instruction and Operation
Address Mode
Opcode(s)
(Hex)
Flags Affected
Dest Source S Z H P/V N C
Note: *This flag value is a function of the result of the affected operation.
— = No Change.
0 = Set to 0.
1 = Set to 1.
V = Set to 1 if overflow occurs.
X = Undetermined.
P = Set to the parity of the result (0 if odd parity, 1 if even parity).
IEF2 = The value of Interrupt Enable Flag 2.
C
7
0
A
3
7
4
0
3
7
4
0
(HL)
A
CY
7
0
A
C
7
0
s
C
7
0
s
