Device Set Up
6
Page 6
Caution!
Note:
After the transport and before switching on the device, make sure that the swiveling
wheels are in the ‘locked’ position.
Make sure that the emFieldPro is placed on a stable and flat surface
Connect mains cable
Connect the mains cable (23) to the socket on the device (11) and connect it to the
mains.
The device may only be connected to earthed sockets
Switching the device
on
Caution!
Caution!
Switch on the device with the power switch (12)
Be aware that connecting the power cable with the power switch turned on may
cause malfunction.
If the transducer is used while in a tilted position, the cooling oil will not reach all
sections of the transducer and damage the transducer due to overheating. For this
reason, it is recommended to place the transducer in a horizontal position as much
as possible.
When separating the transducer from the transducer arm supporter, the pressure of
the gas spring may cause the arm to jump up and the transducer may fall off. Be
sure to hold the transducer with one hand while holding the arm supporter vertically.
When replacing the transducer, be sure to mount the arm support vertically as well.
