Dimensions
Model Capacity Dimensions Fixing Centres Weight Water
(litres) (mm) (mm) (kg) Connections
A B C D E F Empty Full
AP3/10 10 460 350 265 100 370 140 8.5 18.5
1
/
2
"
BSP
AP3/15 15 460 350 310 100 370 140 9.8 24.8
1
/
2
"
BSP
Special notices
These instructions should guide you through the installation, maintenance and
use of the Zip Aquapoint III, however, if you require any further information
please call Zip Customer Service on 0870 608 8888.
• The Zip Aquapoint is an unvented water heater designed for connection
directly to the incoming mains water supply and can serve one or more
outlets using conventional taps.
• Care should be taken that the capacity of the unit chosen is sufficient to
meet the demands of the outlets being supplied.
• The casing is constructed from impact resistant plastic and heat losses are
minimised by the high efficiency polyurethane foam insulation.
• The inner vessel is constructed from glass enamelled steel sheet and
pressure tested to 12 bar.
• A manually re-settable safety cut-out automatically cuts off the electrical
supply to the heating element in the event of a malfunction.
AP3/10, AP3/15 Installation Instructions 5
