Zip Hydroboil HS010 - Earth Continuity Verification; Wiring Diagram; Problem Solving; Maintenance

Zip Hydroboil - Installation & Operating Instructions - 81447 - April 2013 v1.03 Page 10 of 12
Problem Solving
Symptom Possible Cause Solution
Failstodispensewater.
Water isolating valve turned off. Checkwatersupplyvalve.
Blockedfilter,metertube,strainer,jammedball
valveassemblyorairlockintransfertube.
Contact a Zip authorised agent.
Water not boiling.
Nopower. Checkpowersupply.
Faultythermostat,element,cutoutorcontactor. Contact a Zip authorised agent.
Runsoutofboilingwaterand
fails to refill.
Internaladjustment. Contact a Zip authorised agent.
Outlet tap drips.
Overflowfromvent.
Excessivesteamfromvent.
Power“on”butnoheat.
Overload repeatedly tripping
withexcessivesteam.
Overload repeatedly tripping
withoutexcessivesteam.
Maintenance / Cleaning
Formaintenanceandsixmonthlysafetychecks,pleaserefertothePreventativeMaintenancesheetNo.85695included
withtheHydroboil.
MaintenanceshouldbecarriedoutbyaZipauthorisedtechnician.
Cleaning Case: Do not use strong, corrosive, spray or abrasive cleaners.
Cleanthecasewithasoftclothorbrushandmildsoapandwater.
SingleElementUpTo3KwwithOnePole
T.O.LThermalOverLoad
ThermostatControlled
HS140 & HS040 With Contactor
T.O.L:ThermalOverLoad
ThermostatControlled
