Zip Hydroboil HS010 - Spare Parts

Page 11 of 12 Zip Hydroboil - Installation & Operating Instructions - 81447 - April 2013 v1.03
Spare Parts
Key Part No Description
1 SP6245 Cisternlidclampkit
2 SP90120 Cisternlidgasketkit
3 SP90490 Gasketkit
4 SP90083 Floatvalvekit,withfloat
5 SP90069 Jumpervalvekit,withseals
6 SP90102 Cistern float
7 SP90494 Transfertubekit-2.4kW
7 SP90531 Transfertubekit–3kW
8 SP90495 Banjoscrew
9 SP90496 O-ringkitcomplete
10 SP90517 Fascia&lenskit
11 SP90110 Fascialightkit
12 SP3947A Thermostatkit1.5-25litres
12 SP3947A Thermostatkit40litre
13 SP1614T Overloadkit
14 SP90501 Taptopkit
Key Part No Description
15 SP90502 Tapassemblycomplete
17 SP90505 Tapnutkit
18 SP90506 Tapextension
19 SP90486 Elementkit3.0kW230V
20 SP90491 Cleaningholecoverkit
21 SP90492 Draincap&sealkit
 SP90522 Cisternjetnozzlekit
SP90130 Lid clips
 SP81230 Tapflowrestrictor
 SP88318 Cisterntank
 SP88490 Cisterntankgrommetkit
SP6590 Contactor 40 litres
 SP88343 Maintank10L
 SP88344 Maintank15L
 SP88345 Maintank25L
 SP88346 Maintank40L
