Zipro Rook - Parts List

25
EN
PARTS LIST
No. Description Quantity No. Description Quantity
1 Main frame 1 24 Computer cable 1
2 Rear base 1 25 Handlebar column 1
3 Front base 1 26 Computer bolt 4
4 Base cap 4 27 Flat washer 3
5 Level foot 4 28 Locknut 3
6 Hexagonal nut 4 29 Handlebar adjustment knob 1
7 Hexagonal bolt 4 30 Computer 1
8 Curved washer 4 31 Flat washer 1
9 Hexagonal bolt nut 4 32 L/R Handlebar cover, rear/front 1/1
10 L/R Left/right pedal 1/1 33 Cross-head bolt 11
11 L/R Left/right crank 1/1 34 Cross-head bolt 4
12 Saddle height knob 1 35 Steering wheel 1
13 Saddle column 1 36 Heart rate measurement cable 2
14 Saddle horizontal position knob 1 37 Handlebar foam 2
15 Saddle horizontal position knob
washer
1 38 Handlebar cap 2
16 U-bracket for horizontal saddle
positioning
1 39 Curved washer 2
17 Saddle guide cap 2 40 Flat washer 4
18 Saddle guide 1 41 AC adapter 1
19 L/R Saddle guide cover, left/right 1/1 42 Flat washer 2
20 Saddle 1 43 Water bottle 1
21 Hexagonal bolt 2 44 Water bottle holder 1
22 Handlebar column cover 1 45 Screw 2
23 Connecting cable 1
