5.2 Control Subsystem Settings
5.2.1 Configuration Settings
Passwords
The default Password which enables access to every terminal unit setting is 2140. The user may modify
the passwords via the keyboard for the following actions:
Password 1: Configuration
Password 2: Settings
Local Port Communications
Setting Range
Terminal Address
Not sensitive - enter any
number
Baud Rate 4800 Bauds
Stop Bits 1
Frontal Port Parity 0 (no parity) - 1 (even parity)
Remote Port Communications
Setting Range Step
Terminal Address 0 - 254 1
Baud Rate 300 - 19200 Bauds
Stop Bits 1 - 2
Parity 0 (no parity) - 1 (even parity)
Communications Timeout 0 - 100 ms 1
Rated Frequency 50 Hz / 60 Hz
Date and Time
Keyboard updating
5.2.2 General Settings
General Settings
Setting Range Step
CT Ratio 1 - 3000 1
VT Ratio 1 - 3000 1
Transducers (*)
Constant 0.00 to 99999.99
Quantity kw, kVAr, A, kV
Type
2.5; 0.5; 1.0; 0-1 mA
(*)The transducer output type depending on the model.
