ZIV 7IRD-A - Page 70

Chapter 6. Description of Operation of Protection Subsystem
M7IRDA2003I
7IRD-A/J/M: Distribution Protection & Control Terminal
© ZIV APLICACIONES Y TECNOLOGÍA, S.L.U. 2020
6-30
Table 6-1: Event Record
Function Event oct. bit
Inputs (Expansion)
[19]
Status Contact Input IN-1 Activation (expansion) 2 1
Status Contact Input IN-2 Activation (expansion) 2 2
Status Contact Input IN-3 Activation (expansion) 2 3
Status Contact Input IN-4 Activation (expansion) 2 4
Status Contact Input IN-5 Activation (expansion) 2 5
Status Contact Input IN-6 Activation (expansion) 2 6
Status Contact Input IN-7 Activation (expansion) 2 7
Status Contact Input IN-8 Activation (expansion) 2 8
Status Contact Input IN-1 Deactivation (expansion) 3 1
Status Contact Input IN-2 Deactivation (expansion) 3 2
Status Contact Input IN-3 Deactivation (expansion) 3 3
Status Contact Input IN-4 Deactivation (expansion) 3 4
Status Contact Input IN-5 Deactivation (expansion) 3 5
Status Contact Input IN-6 Deactivation (expansion) 3 6
Status Contact Input IN-7 Deactivation (expansion) 3 7
Status Contact Input IN-8 Deactivation (expansion) 3 8
Recloser [04]
(7IRD-A/J Models)
Recloser External Lockout Reset 1 3
Recloser External Lockout 1 4
Recloser Unblocked 1 5
Recloser Blocked 1 6
Recloser Lockout Due To Switch-On-To-Fault 1 7
Recloser Lockout Due To Lack Of Rated Voltage 1 8
Recloser Lockout Due To Breaker Failure 2 1
Recloser Lockout Due To Permanent Fault 2 2
Recloser Lockout Due To Open Breaker Status 2 3
Recloser Lockout Due To Unsatisfied Reclosing Conditions 2 4
Recloser Lockout Due To Sequence Check Failure 2 5
Reclose Command 2 6
Recloser Reset 2 7
Reclose Sequence In Progress 2 8
Command [05] Trip Blocked Due Incorrect Settings 1 3
Current Detected With Open Breaker Status (52b contact) 1 4
Breaker Close Command Failure 1 5
Breaker Open Command Failure 1 6
Breaker Close Command 1 7
Breaker Open Command 1 8
Excessive Number Of Trips 2 6
