Chapter 6. Description of Operation of Protection Subsystem
M7IRDA2003I
7IRD-A/J/M: Distribution Protection & Control Terminal
© ZIV APLICACIONES Y TECNOLOGÍA, S.L.U. 2020
6-42
Table 6-3: Auxiliary Outputs
Num Name Description Function
86 DD BI DD + BI FL (7IRD-A/J)
The fault persists at the end of
the reclose sequences or
internal block of the Recloser
due to a fault when energizing
the line.
87 BLQ RBM + RBE (7IRD-A/J)
Recloser blocked manually or
externally.
88 OR Reclose Command (7IRD-A/J)
Sending of the signal of close
of the command module.
89 CC Reclose Sequence In Progress (7IRD-A/J)
OR Logic of the recloses
sequences.
90 RBM Recloser Blocked (7IRD-A/J)
Signals generated through the
HMI, communications, or
through an external status input
91 RBE Recloser External Lockout (7IRD-A/J)
93 SRP Recloser Reset (7IRD-A/J)
Recloser at rest after a security
period following a fault, or a
security period following an
external close when a fault did
not occur.
94 SRES Recloser In Service (7IRD-A/J)
Signal corresponding to the
Recloser In Service setting.
95 SUIM_A2
Phase A Instantaneous 2 Overcurrent Mask
Enabled Trip Output (7IRD-J)
Unit Trips. Affected by their
corresponding trip mask.
96 SUIM_B2
Phase B Instantaneous 2 Overcurrent Mask
Enabled Trip Output (7IRD-J)
97 SUIM_C2
Phase C Instantaneous 2 Overcurrent Mask
Enabled Trip Output (7IRD-J)
98 SUIM_N2
Ground Instantaneous 2 Overcurrent Mask
Enabled Trip Output (7IRD-J)
99 E1T1 Physical Input 1 (circuit board 1)
Active outputs depend on the
corresponding input.
100 E2T1 Physical Input 2 (circuit board 1)
101 E3T1 Physical Input 3 (circuit board 1)
102 E4T1 Physical Input 4 (circuit board 1)
103 E5T1 Physical Input 5 (circuit board 1)
104 E6T1 Physical Input 6 (circuit board 1)
105 E7T1 Physical Input 7 (circuit board 1)
106 E8T1 Physical Input 8 (circuit board 1)
107 E1T2 Physical Input 1 (circuit board 2)
108 E2T2 Physical Input 2 (circuit board 2)
109 E3T2 Physical Input 3 (circuit board 2)
110 E4T2 Physical Input 4 (circuit board 2)
111 E5T2 Physical Input 5 (circuit board 2)
112 E6T2 Physical Input 6 (circuit board 2)
113 E7T2 Physical Input 7 (circuit board 2)
114 E8T2 Physical Input 8 (circuit board 2)
The outputs are configured at the factory, but can be modified by the user using ZiverCom
®
program through the local communications port.
