1.5 The working principle of full height turnstiles
1.5.1 After the power is turned on, the system will perform self-check. If no fault is detected, the
device will operate as usual. If a fault is detected, the system will display the related messages on
the LCD screen. This can be useful for error checking and troubleshooting.
1.5.2 When the reader detects a valid signal, the buzzer will give pedestrians a voice prompts to
remind pedestrians have been successful credit card. And then, the reader sends signals to the
access controller to request permission to pass through the passage. After the access controller
send the signals to the control panel, the control panel will send out a pass.
1.5.3 After receiving the signal from the access controller, the control panel sends signals to the
direction indicator and solenoid. Then the direction arrow will turn green. Also the solenoid will
loose that the pedestrian can push the rod to pass the passage.
1.6 Product related parameters
Dimensions(mm)
FHT2000: L = 1400, W = 1310, H = 2200
FHT2400: L = 1400, W = 1370, H = 2200
Communication
Interface
RS232 Input voltage
AC 100 - 120V/200 - 240V,
50 - 60Hz
Input control signal Switching signal
Output
voltage
DC 24V
Working environment Indoor/Outdoor
Relative
humidity
25% - 75%
Temperature
-28℃~ 60℃
Pass speed
RFID：Maximum 30/minute
Fingerprint：Maximum25/minute
Face：Maximum 15/minute
Vein：Maximum 15/minute
