ZKTeco LF10 - Device Installation

2
Device Installation
1.4m
1 2
3
①
②
Please insert the cable into the terminal before installation.
①Attach the mounting template sticker to the wall, and drill holes according to
the mounting paper.
②Fix the back plate on the wall using wall mounting screws.Attach the device to
the back plate.
③Fasten the device to the back plate with a security screw.
