ZKTeco SpeedFace-V3L - Terminal Block; Installation Environment

2
Note:
Ÿ This manual only take SpeedFace-V3L as an example for detailed introduction, and
the functions of SpeedFace-V3LM1 will not be repeated.
Ÿ Features and parameters with mark are not available in all devices.★
NC
COM
NO
SEN
GND
BUT
AUX
GND
BELL+
BELL-
ALARM+
ALARM-
485A
485B
WD0-OUT
WD1-OUT
INWD0
INWD1
GND
12V-OUT
TX+
RX+
TX-
RX-
12VIN
12VIN
12VIN
GND
GND
GND
Terminal Block
Installation Environment
Please refer to the following recommendations for installation.
AVOID DIRECT
SUNLIGHT
AND EXPOSURE
AVOID GLASS
REFRACTION
KEEP EFFECTIVE
DISTANCE
0.3-1.2m
INSTALL
INDOORS ONLY
