Zodiac EIXPERT - EiXpert Installation; Install the cell

3
Informaon before installaon
Carton Contents:
1 x Power Pack (control box)
1 x Electrolyc Cell
1 x Owner/Operators Manual
1 x Installaon Screw Set
1 x Power Pack Hanging Template
Technical specicaons
Power supply voltage 220 - 240 Vac-50 Hz
Electric power
Max. 140 W
Protecon index IPX3
Control box size (W x L x D) 285 x 405 x 115 mm
Weight (box + cell) Minimum 7.1 kg
EiXpert Installaon
B
o
o
s
t
L
o
w
B
a
c
k
S
e
le
c
t
Install the cell
(a) Cell MUST be installed horizontally downstream of the heater and lter. It MUST be the last piece of
equipment in the return line to the pool.
(b) The posion of the cell, relave to other equipment, should be such that gases generated under normal
operaon should not accumulate in any receptacle or pipework. Thus, the cell should be posioned in-line
AFTER all receptacles where gases in excess of 2 litres may accumulate under normal operaon. e.g. lter
tanks, header tanks, solar systems, by-pass pipe loops, heaters, etc.
(c) If a valve is required aer the cell it should always be a non-return valve not a manually operated version.
Torque = 1.2 N.m (= 12.2 kg.cm)
