2.3 I Installing the sensors (pH & pH/ORP, depending on model)
• Never wipe the sensor using a cloth or paper ssue, as this may damage it.
• A badly-installed sensor may give false readings and cause inappropriate operaon of the appliance.
Neither the manufacturer nor the appliance shall be liable in this event.
• Carefully unscrew the protecon tube from the sensor ( ). Keep the protecon tube for storing the sensor over
winter.
• Rinse the end of the sensor with tap water and shake o excess water ( ).
• Loosen the nut xed to the sensor holder ( ).
• Install the pH sensor and/or the ORP sensor (supplied) in the sensor holder so that the sensor located at the end
of the holder is always submerged in the water owing through the piping( ). Ensure that the cable is not
tangled.
• To avoid damage, sensor end must be located in the center of the pipe, not further.
• The sensor must always be installed vercally, or where necessary, at a maximum angle of 40°( ).
• Once the sensor is installed it can be connected to the BNC socket on the control box, see § “2.5.2. Connecng the
control box” ).
• The sensor must then be calibrated, see § “4.4 I Calibrang the sensors (pH or pH/ORP models)”.
pH
ORP
40°
