14
2.4.2. Installing the pH minus sucon line
• Cut a suitable length of transparent hose from the coil (supplied) to connect the container of pH-minus to the pH
pump.
• Unscrew the connector cap and aach the hose to the connector at the inlet of the pH pump, see gure . Screw
the cap in place.
• Drill two holes into the cap of the pH minus container, see gure :
- One hole suitable for the diameter of the hose ( )to aspirate the product.
- One smaller hole to prevent the container from becoming deformed during aspiraon of the product.
• Pass the free end of the sucon hose ( ) through the hole made in the cap ( ) and put the ceramic weight pro-
vided ( ) and the support p on the hose, see gure .
• Ensure that all connections are correct and watertight before operating the appliance.
pH-minus
Do not place the pH-minus container directly beneath electrical equipment in the technical room to prevent
risk of corrosion resulng from potenal acidic vapours.
EN
