Zodiac pH Perfect - Technical Specifications; Dimensions and Performance Data

Dimensions: 215 (L) x 173 (W) x 110mm (H) Maximum back pressure: 1.5 bar
Weight: 1.6kg (appliance, sensor, tube and pipes) pH scale: 6.2pH - 8.0pH
Power Supply: 50Hz, 230V AC pH check range: 0.0pH - 14.0pH
Consumption: 7W Appliance accuracy: +/- 0.1pH
Pump flow rate: 1.5l/h (or 25ml/min) Calibration of sensor:
Automatic
215mm
195mm
80mm
110mm
30mm
95mm
pH Perfect
158mm
195mm
173mm
215mm
43mm
47mm
90mm
Front
Side
