ZOLL R Series Operator's Guide

9650-0912-06 Rev. G ZOLL R Series Operator’s Guide v
Transferring a Full Disclosure File to a Compact Flash Card ........................................... 11-3
Transferring Device Check and Activity Log Files to a Compact Flash Card.................... 11-3
Transferring Files Through the USB Port (Optional)......................................................... 11-4
Transferring Full Disclosure Files Through Wi-Fi (Optional)............................................. 11-5
Transferring Device Check and Activity Log Files Through Wi-Fi (Optional).................... 11-6
Related Wi-Fi Messages ...........................................................................................11-7
Chapter 12 Maintenance
Routine Procedures..........................................................................................................12-2
Daily Visual Inspection ..............................................................................................12-2
Code Readiness Test ............................................................................................... 12-3
Manual Defibrillator Testing............................................................................................... 12-3
Defibrillator Testing with Paddles ............................................................................. 12-4
Defibrillator Testing with Hands-Free Therapy Electrodes .......................................12-5
Pacer Testing ............................................................................................................ 12-5
Recorder Check ........................................................................................................ 12-6
Code Readiness Log ................................................................................................ 12-6
Setting Time and Date ..............................................................................................12-8
Cleaning the R Series Unit .......................................................................................12-8
Loading Stripchart Paper ..........................................................................................12-9
Cleaning the Print Head .......................................................................................... 12-10
Operator’s Checklist for R Series Product ............................................................. 12-11
Chapter 13 Troubleshooting
Code-Ready .............................................................................................................. 13-1
Monitor ...................................................................................................................... 13-2
Recorder ...................................................................................................................13-3
Pacer ........................................................................................................................13-4
Defibrillator ................................................................................................................13-5
AC Charger ...............................................................................................................13-7
Appendix A Specifications
Defibrillator Specifications ..................................................................................................A-2
Battery Pack Specifications ........................................................................................A-6
IEC 60601-1-2 Specifications .............................................................................................A-7
Electromagnetic Emissions Declaration .....................................................................A-7
Electromagnetic Immunity Declaration (EID) ..............................................................A-8
EID for Life-Support Functions ...................................................................................A-9
Recommended Separation Distances from RF Equipment for the R Series
Life-Support Functions ...........................................................................................A-10
EID for Non–Life-Support Functions .........................................................................A-11
Recommended Separation Distances from RF Equipment for the R Series
Non–Life-Support Functions ...................................................................................A-12
R Series Rectilinear Biphasic Waveform Characteristics .................................................A-13

ZOLL R Series Specifications

General

Defibrillator Type	Manual and AED
Pacing	Yes
ECG Monitoring	Yes
SpO2 Monitoring	Yes
FAST-SpO2	Yes
IP Rating	IP55
Defibrillator Waveform	Biphasic
Energy Levels	1-360 Joules
Display	LCD
Pacer Type	Demand
Pacer Rate	30-180 ppm
Pacer Output	0 – 140 mA
EtCO2 Monitoring	Optional
NIBP Monitoring	Optional
Temperature Monitoring	Optional
Printer	Integrated
Battery Type	Lithium-ion
CPR Feedback	Yes
Data Storage	Internal memory
Connectivity	USB
