Zoom 4501 - Wireless Features: WDS Encryption; WDS Encryption Key Details

Field Entry
Remote AP
MAC 3
Refers to the MAC Address of the WDS-enabled Access Point (AP).
Enter the address in the field
. Only authorized APs can access this
router through the WDS feature to extend the WLAN coverage range.
Remote AP
MAC 4
Refers to the MAC Address of the WDS-enabled Access Point (AP).
Enter the address in the field
. Only authorized APs can access this
router through the WDS feature to extend the WLAN coverage range.
Encryption
type
By default, the Encryption type is None.
If you previously selected a WEP or WPA-PSK/WPA2-PSK encryption
type when using the Advanced > Basic Setting > Wireless Setting page, the
values you chose will appear on this menu.
For WEP encryption, choose WEP. For WPA, choose TKIP or AES.
Encryption
key
The Encryption key field appears on the WDS Setting page if you entered
a WPA-PSK/WPA2-PSK encryption key when using the Advanced >
Basic Setting > Wireless Setting page.
Enter the same key that you defined previously for the Preshare Key on
the Advanced > Basic Setting > Wireless Setting page. The maximum value
is 32 characters. The minimum value is 8 characters.
Write your key in the space below for future reference, and then enter it
in the Encryption Key field:
— — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — —
4 Click Save.
32 3G Wireless-N Router User Guide
