Zoom A1X FOUR User Manual

Turn the MAA-1 power on.
1.
Set to the ON position.
will light red.
When connecting a condenser mic or other device that requires phantom power, set it to the +48V
position.
NOTE
When connecting devices that are not compatible with phantom power, do not set to +48V. Doing
so could damage the device.
Adjusting the MAA-1 input level
1.
Turn .
Adjust so that
lights green.
If the input level is too high,
will light red.
12

Zoom A1X FOUR Specifications

General

Number of Simultaneous Effects	5
Looper	30 seconds
Weight	610 g (without batteries)
Sampling Frequency	44.1 kHz
A/D Conversion	24-bit
D/A Conversion	24-bit
Display	LCD
Type	Multi-effects processor
Drum Machine	Yes
Patches	50
Rhythm Patterns	68
Output	1/4'' stereo output
USB	USB 2.0
Power	4 AA batteries, AC adapter (optional)
Frequency Response	20 Hz - 20 kHz +1 dB, -3 dB (10 kΩ load)
Input	1 x 1/4" (guitar), 1 x 1/8" (aux)
Effects	Guitar, bass, acoustic guitar
