Zoom A1X FOUR User Manual

Connecting a mic using the MAA-1
Using the MAA-1 to connect a mic to the , it can be enjoyed with instruments that do
not have pickups, including harmonicas, violins, trumpets, saxophones and other string and brass instru-
ments.
Putting batteries into the MAA-1
1.
Press and slide the battery compartment cover down to open it.
2.
Insert 2 AA batteries.
3.
Close the battery compartment cover.
11

Zoom A1X FOUR Specifications

General

Number of Simultaneous Effects	5
Looper	30 seconds
Weight	610 g (without batteries)
Sampling Frequency	44.1 kHz
A/D Conversion	24-bit
D/A Conversion	24-bit
Display	LCD
Type	Multi-effects processor
Drum Machine	Yes
Patches	50
Rhythm Patterns	68
Output	1/4'' stereo output
USB	USB 2.0
Power	4 AA batteries, AC adapter (optional)
Frequency Response	20 Hz - 20 kHz +1 dB, -3 dB (10 kΩ load)
Input	1 x 1/4" (guitar), 1 x 1/8" (aux)
Effects	Guitar, bass, acoustic guitar
