Zoom A1X FOUR User Manual

Adjusting the torque
1.
Insert a 5 mm hex wrench into the torque adjustment screw on the side of the pedal.
2.
Turn it clockwise to tighten the pedal and counterclockwise to loosen it.
Loosen Tighten
NOTE
Be careful because loosening the torque adjustment screw too much could cause it to become discon-
nected internally, making it impossible to keep the pedal in a xed position.
58

Zoom A1X FOUR Specifications

General

Number of Simultaneous Effects	5
Looper	30 seconds
Weight	610 g (without batteries)
Sampling Frequency	44.1 kHz
A/D Conversion	24-bit
D/A Conversion	24-bit
Display	LCD
Type	Multi-effects processor
Drum Machine	Yes
Patches	50
Rhythm Patterns	68
Output	1/4'' stereo output
USB	USB 2.0
Power	4 AA batteries, AC adapter (optional)
Frequency Response	20 Hz - 20 kHz +1 dB, -3 dB (10 kΩ load)
Input	1 x 1/4" (guitar), 1 x 1/8" (aux)
Effects	Guitar, bass, acoustic guitar
