Using the Tuner
ZOOM A2
11
A8
4 0
42
NOTE
Pitch is high Pitch is correct
Indication turns faster the more
the pitch is off.
Pitch is low
Tune other strings in the
same way.
The right side of the display
shows a symbol that indicates
by how much the tuning is off.
When you turn the A2 off and on again,
the reference pitch setting will be reset
to 40 (center A = 440 Hz).
Adjusting the reference pitch of the tuner
Return to play mode
Turn parameter knob 1.
While the reference pitch value is shown,
turn parameter knob 1 to adjust it.
Press one of the [W]/[Q] foot switches.
If required, you can fine-adjust the reference pitch of the A2 tuner. The default
setting after power-on is center A = 440 Hz.
The current reference pitch is shown.
The adjustment range is 35 – 45 (center A = 435
to 445 Hz).
When you release the parameter knob, the display
indication will return to the previous condition
after a while.
eA2.fm 11 ページ ２００５年１０月１４日 金曜日 午後５時２９分
