ZOOM A2
21
Foot switch is pressed
Foot switch is
pressed again
Original sound
Delay sound
Hold
Using an Optional Foot Switch or Pedal
The A2 is equipped with a [CONTROL IN] jack designed for connection of an optional foot switch or
expression pedal. This section explains how to use these accessories.
Using the foot switch
(FS01)
Connecting the optional foot switch FS01 to the
[CONTROL IN] jack allows functions such as
switching banks, performing tap tempo input, and
switching the feedback control function on and
off.
1.
Plug the cable from the FS01 into the
[CONTROL IN] jack, and then turn the
A2 on.
2.
Set the Module selector to the
"CONTROL" position.
The A2 goes into edit mode. You can now make
settings for the expression pedal and foot switch.
3.
Turn parameter knob 2 to select one
of the following functions for the foot
switch.
●
bP (bypass/mute)
The foot switch controls bypass or mute on/off.
This has the same effect as pressing both [W
]/
[Q
] foot switches at the same time in play
mode or manual mode.
●
tP (tap tempo)
Pressing the foot switch repeatedly can be used
to set the interval for the rhythm function or to
make settings for effect parameters supporting
the tap function.
●
bU (bank up)
Each push of the foot switch switches to the
next higher bank. This has the same effect as
pressing the BANK [+] key.
●
rH (rhythm on/off)
The foot switch controls start/stop of the
rhythm function. This has the same effect as
pressing the RHYTHM [R
/P
] key.
●
dH (delay hold)
The foot switch controls on/off of the delay
hold function. When a patch using the hold
function is selected, pressing the foot switch
eA2.fm 21 ページ ２００５年１０月１４日 金曜日 午後５時２９分
