ZOOM A2
35
Specifications
Effect types
47
Effect modules
Max. 8 simultaneous modules
Patches
User area: 10 patches x 4 banks
Preset area: 10 patches x 4 banks
Sampling frequency
96 kHz
A/D converter
24 bit, 64 times oversampling
D/A converter
24 bit, 128 times oversampling
Signal processing
32 bit
Frequency response
20 Hz – 40 kHz +1 dB -3 dB (with 10 kilohms load)
Display
2-digit 7-segment LED
Parameter LEDs
Input
Standard mono phone jack
Rated input level
-20 dBm
Input impedance
1 megohm
Output
Standard stereo phone jack (doubles as line and headphone jack)
Maximum output level
Line: +5 dBm (output load impedance 10 kilohms or more)
Phones: 20 mW + 20 mW (into 32 ohms load)
Control input
For FP02 (FP01)/FS01
Power requirements
AC adapter
9 V DC, 300 mA (center minus plug) (ZOOM AD-0006)
Batteries
Four IEC R6 (size AA) batteries,
Approx. 7.5 hours continuous operation (alkaline batteries)
Dimensions
162 mm (D) x 156 mm (W) x 65 mm (H)
Weight
700 g (without batteries)
Options
Expression pedal FP02/ Foot switch FS01
• 0 dBm = 0.775 Vrms
• Design and specifications subject to change without notice.
Troubleshooting
●
Volume is low
Adjust the patch level (
→
p. 9) or master level
(
→
p. 33). When using a pickup with low
output, start the A2 in HI-GAIN mode (
→
p. 6).
●
Matching problem with particular
pickup or guitar amplifier
Check the PICKUP SELECT and AMP
SELECT settings.
●
Delay/reverb effect does not work
DELAY/REVERB module is inactive while a
rhythm pattern is playing. Stop rhythm
playback (
→
p. 12).
●
High level of noise
Adjust ZNR module. Be sure to use only a
ZOOM AC adapter (ZOOM AD-0006).
●
Battery life is short
Are manganese batteries being used?
Continuous operation time is 7.5 hours with
alkaline batteries. The use of alkaline batteries
is recommended.
eA2.fm 35 ページ ２００５年１０月１４日 金曜日 午後５時２９分
