ZOOM A2
14
Editing a Patch
The patches of the A2 can be freely edited by changing the effect parameter settings. Try editing the
currently selected patch to create your own sound.
M D
O
F
Select the effect module
Turn the Module selector to select the
effect module to edit. The following
settings are available.
To switch an effect
module on and off
To switch the selected effect
module between on and off, press
one of the [W]/[Q] foot switches.
(1) MODEL module
(2) MIC module
(3) COMP/LIMIT module
(4) LO EQ module
(5) HI EQ module
(6) ZNR module
(7) MOD/SFX module
(8) DELAY/REVERB module
(9) CONTROL module
(10) GLOBAL module
When you set the Module selector to a position
other than "PLAY", the A2 switches to edit mode,
and the effect type currently selected for the
respective module is shown. In edit mode, a dot
appears in the bottom right of the display.
Dot indicates that
unit is in edit mode
Effect type
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
When the module is off, the indication "oF"
appears on the display.
HINT
CONTROL and GLOBAL are special
modules that serve for making settings
that affect the entire unit, such as
selection of pedal operation. These
modules cannot be switched on/off.
HINT
You can switch to edit mode from play
mode or manual mode.
