Zoom GFX-4 User Manual

DELAY/REVERB module
26
ZOOM GFX-4
Effect Types and Parameters
This module contains various echo effects such as delay and reverb.
TYPE 1
HALL
This is a reverb effect which simulates a medium-size concert hall.
TYPE 2
ARENA
This is a reverb effect which simulates a large arena.
TYPE 3
ROOM
This is a reverb effect which simulates a small room.
TYPE 4
GARAGE
REVTIM
TONE
REVMIX
1 – 30
0 – 10
0 – 50
This is a reverb effect which simulates a garage with a high amount of early reflections.
TYPE 5
DLYHAL
(Delay Hall)
(Hall)
(Arena)
(Room)
(Garage)
This is a combined delay + hall reverb effect.
Adjusts the reverb time. Adjusts the effect sound character. Adjusts the effect sound mixing ratio.
TYPE 6
DLYROM
DLYTIM
DLYMIX
REVMIX
(Delay Room)
1 – 50
0 – 50
0 – 50
This is a combined delay + room reverb effect.
Adjusts the delay time in 10-ms steps. Adjusts the delay sound mixing ratio. Adjusts the reverb sound mixing ratio.
TYPE 13
PDLPIT
POSI
TYPE
TONE
(Pedal Pitch)
bF, AF
1 – 10
0 – 10
This is a pitch shifter controlled by the pedal.
Selects the connection position of the
MODULATION module. The
following two settings are available.
bF: Before the DRIVE module
AF: After the EQUALIZER module
Selects the pedal pitch type. Adjusts the effect sound character.
TYPE
[Pedal pitch type]
1
2
3
4
5
± 0 cent
± 0 cent
± 0 cent
± 0 cent
± 0 cent
-100 cent
+1 octave
+2 octave
-1 octave
-2 octave
6
7
8
9
10
Doubling
-1 octave + original sound
-700 cent + original sound
- ∞ (0 Hz) + original sound
- ∞ (0 Hz) + original sound
Detuned sound + original sound
+1 octave + original sound
+500 cent + original sound
+1 octave
+1 octave + original sound
For the effect types PDLWAH (pedal wah) and PDLPIT
(pedal pitch) of the MOD module only, there is a special
key to call up the edit screen.
Pressing the PEDAL WAH/PEDAL PITCH key in
manual mode or program mode toggles the unit between
the PDLWAH and PDLPIT edit screens.
When PDLWAH or PDLPIT is selected, you can adjust
the effect parameters with the knobs of FX panel 2. In this
case, the following settings are established automatically.
• MODULATION module = ON
• MODULATION module effect type
= PDLWAH or PDLPIT
• UP if RTMSET display EP-MOD parameter = oF
■ PEDAL WAH/PEDAL PITCH key
