Zoom GFX-4 User Manual

5
ZOOM GFX-4
Controls and Functions
Controls and Functions
Top Panel
Rear Panel
AMP SIM (amp simulator)
key & LED
LEVEL/NAME (level name)
key & LED
ZNR key & LED
STORE key
MANUAL/CANCEL key & LED
GROUP/BANK
indicator
Display
Module keys & LEDs (COMP/OD/ENV, DRIVE, EQUALIZER,
PEDAL, MODULATION, PEDAL WAH/PEDAL PITCH ,
DELAY/REVERB)
/ / / keys
TYPE DOWN/UP key
Parameter knobs
Foot switches 1 - 3 & LEDs
Expression pedal
ACTIVE NORMAL switch
INPUT jack
OUTPUT MONO jack
OUTPUT STEREO/PHONES jack
MASTER LEVEL knob
POWER switch
AC adapter connector
[FX panel 1 - 3]
BANK foot switch
