5.3 Function key
At the bottom of the main interface is the function key column, from F1-F8 are as below:
1
st
interface function key:
F1：Main interface shift key, press to enter into 2
nd
interface；
F2：OM & Reeving setting key（details refer to 5.3.1）；
F3：Data checking，press to check analog input & digit output of iFLEX5 （details
refer to 5.3.2）
F4：System setting key,（details refer to 5.3.3）
F5：CAN-Bus checking，press to check the bus mode between controller and console
（details refer to 5.3.4）
F8：Alarm stop key，press to stop the alarming sound of the system
2
nd
interface function key:
F1：Main interface shift key, press to enter into 1
st
interface；
F3：Angle limitation setting key (details refer to 5.3.5)
F4：Time setting key (details refer to 5.3.5)
F8： Alarm stop key，press to stop system alarming
