User Manual ZFG 3.0
- 8-
3.3 Performing a measurement
3.3.1 Switch on device
After preparation of measurement (chapter 3.2 - Preparation) switch on the device by pressing the
<On/Off> Button. The following start screen appears:
The current date/time and battery voltage with load capacity are shown. If you want all data to be
saved on SD-card, plug it in now.
3.3.2 Start measurement
Press <OK> Button to start a measurement. The screen shows the following:
The display shows the current measurement type (i.e. diameter of load plate and mass of drop
weight). If available, switch to desired measurement type (see chapter 4.5.3 Type).
In the second line, the command to execute the 1
st
drop appears. A single beep signals readiness.
After executing the 1
st
pulse, the display shows the deflection s
1.
The beep signals the readiness for the execution of the 2
nd
pulse.
This procedure repeats until the 3
rd
pulse.
After that, all three deflection values are shown and it a double beep signal sounds. The
measurement will be saved automatically on SD-card. By pressing the Button <OK>, the results are
shown.
ZFG 3.0
Mi 12.01.11
11:58:37
Battery: 5,4V
Zorn Instruments
Measure: 300mm/10kg
Execute 1st pulse
Measure: 300mm/10kg
s
1
: 0.312 mm
Execute 2nd pulse
Press <OK>
s
1
: 0.312 mm
s
2
: 0.303 mm
s
3
: 0.285 mm
To Next Page
