User Manual ZFG 3.0
- 14-
6 Technical data
6.1 Mechanic and terms
1. Handle
2. Top limit stop with release device
3. Guide rod
4. Handle on drop weight
5. Drop weight
6. Transport lock
7. Set of plate springs
8. Anti-tip device
9. Centering
10. Carrying handle
11. Sensor jack on load plate
Loading
device
Load plate
Picture 3: Mechanic of LWD
