ZORN INSTRUMENTS ZFG 3000 GPS User Manual

- 13 -
11. Technical data for settlement gauge
Measuring device dimensions 300x270x170 mm
Measuring device weight approx. 4 kg
Settlement measuring range 0.3 to 5 mm
± 0.02 mm
Sensor
acceleration range ±100 g
Frequency range 0 to 500 Hz
Temperature range 0 to 50 ° C
Power supply
Battery pack 4.8V, 4500mAh
(4x NiMH)
Power supply ES18E12-P1J
Input 100-240V 50/60 Hz
Output 12V / 1.5A
Automatic switch-off
when not in use 4 min
when battery is empty < 4.5V
12. Scope of delivery
The package includes:
 ZFG3000 GPS electronic measuring device including GPS module *
 10 kg loading device with triangular catch handle*
 Loading plate (300 mm) with integrated acceleration sensor
 Measuring cable (1.5 m)
 SD card (min 1 GB)
 USB SD card reader *
 ZFG 3000 software (CD-ROM) *
 Charging device ES18E12-P1J
 12V car – connecting cable
 Operating instructions / brief instructions
* depending on the configuration and device type (ZFG 3000 ECO without the GPS, with
round catch handle , Software optional)
