3. Carrying out a measurement
3.1 Switching the device on
Once pre-loading has been carried out, the settlement gauge should be switched on using the
<On/Off> switch. To prevent unintentional switching on of the device, the <On/Off> button
must be pressed for at least two seconds when switching on.
We 11.02.09
11:58:37
Batt:
Zorn Instruments
The current date/time and battery status are displayed. Please insert the SD card now. to
enable data to be saved on the SD card.
3.2 GPS receiver function*
GPS = Global Position System; used for position-fixing
The GPS module installed as standard receives satellite signals in the open air. Reception is
only available to a limited extent under coverings and in enclosed rooms. The satellite signals
are received by the GPS module to fix the current position. Depending on the satellite signal
strength, the device requires between 30 and 120 seconds to display the location coordinates
on its display. The location coordinates are now displayed in place of the name Zorn
Instruments.
If no satellite signals can be received (e.g. due to enclosed rooms) measurement and saving
can also be carried out without position-fixing.
3.3 Text input function
Via the text input function, it is possible to add text to a measure. The user can insert text at
the beginning of a measurement. By default, the text input function is disabled (to enable the
function, see chapter 4.4 Settings).
When the device and text input function is activated, press <OK> to start a measurement.
First, the following text input appears on the display:
From the upper three lines, a sign can be chosen.
Function of the buttons:
<+/-> Move the cursor (underline) to navigate to a character
<Print> Choose a character and adds it to the end of the text-string (max. 16
characters possible)
<Mode> Deletes the last character of the text string
<OK> Finishes text inserting and starts measuring
0123456789ABCDEF
HIJKLMNOPQRSTUV
WXYUZ /-+._,#
<+> / <-> change
exampletext 01
