Specication
Weight and Physical Dimensions
Without a spool (W x D x H) 350 x 360 x 505 mm (13.8 x 14.2 x 19.9 in)
With a spool 350 x 430 x 505 mm (13.8 x 16.9 x 19.9 in)
Shipping Box 470 x 480 x 570 mm (18.5 x 18.9 x 22.4 in)
Device weight 16 kg (32 lb)
Shipping weight 26 kg (57.3 lb)
Printing
Technology
LPD (Layer Plastic Deposition) – depositing
melted material layer by layer onto the build
platform
Layer resolution 90 - 390 microns
Minimal wall thickness 400 microns
Platform levelling
Automatic measurement of
platform points’ height
Device
Build volume 200 x 200 x 180 mm (7.9 x 7.9 x 7.1 in)
Material Container Spool
Material Diameter 1.75 mm (0.069 in)
Nozzle diameter 0.4 mm (0.016 in)
