ZXR105900ESeriesHardwareManual
FIGURE1ZXR105900ESYSTEMSCHEMATICDIAGRAM
ZXR105900Esystemadoptsstandard19-inchplug-inbox,which
canbeinstalledoutsideseparatelyorwithinthestandardcabinet.
HardwareStructure
ZXR105928E
TheheightofZXR105928Echassisis1U(1U=44.45mm).Itcan
provide24gigabitEthernetelectricalinterfaces(RJ45)andsup-
portCAT5orabovetwistedpaircable,aswellasQXFBandQGLB
upstreamsubcards.
ThefrontviewofZXR105928EisasshowninFigure2.
FIGURE2ZXR105928EFRONTVIEW
TherearviewofZXR105928EisasshowninFigure3.
FIGURE3ZXR105928EREARVIEW
ZXR105928E-FI
TheheightofZXR105928E-FIchassisis1U(1U=44.45mm).It
canprovide24gigabitEthernetopticalinterfaces(SFP)andsup-
8CondentialandProprietaryInformationofZTECORPORATION
