ZXR105900ESeriesHardwareManual
�Linevoltagewaveformdeviationfactor(WDF)<5%
MonitoringInterface
ZXR105900Eprovides2RJ45interfaces.ALARMINinterfacepro-
videsapairofdrynodeinputand3pairsofdrynodeinputand
ALARMOUTinterfaceprovides4pairsofdrynodeoutput.Figure9
showsinterfaces.
FIGURE9ZXR105900EMONITORINGINTERFACEDIAGRAM
14CondentialandProprietaryInformationofZTECORPORATION
