Chapter4Installation

FIGURE13FIXINGDEVICE

CableLaying

ZXR105900Ecablesconsistofpowercable,serialconsolecable,

networkcableandber .

PowerCableConnection

Powercablecanbedividedintotwotypesaccordingtodifferent

powermodules:ACpowercableandDCpowercable.

1.ConnectionofACPowerCable

AsshowninFigure14,standardprintpowercableisusedas

theACpowercable.

FIGURE14ACPOWERCABLE

ConnectoneendofACcabletotheACsocketofZXR105900E

ACpowermodule,andconnecttheotherendto220VAC

socket.

2.ConnectionofDCPowerCable

i.DC-48VpowercableC-PWR-084isshowninFigure15.

CondentialandProprietaryInformationofZTECORPORATION17
