Touchscreen User Manual – Issue 1
Zytronic X-Y Controller (Serial and USB) 10
Figure 2: Through Touch integration with a front sacrificial glass and front bezel which
can be made from either plastic or metal
Figure 3: Through Touch integration with a front sacrificial glass only
Side Profile
If a front metal bezel is used,
earth the front metal bezel and
D
is
p
la
y
to a common earth
p
oin
t
3mm Gasket
Touchscreen
Display
Front Sacrificial Panel
(Glass or Polycarbonate)
Front Bezel
3mm Gasket
Earth the Display to common
earth point
3mm Gasket
Touchscreen
Display
Front Sacrificial Panel
(Glass or Polycarbonate)
