Touchscreen User Manual – Issue 1
Zytronic X-Y Controller (Serial and USB) 20
3.0 INSTALLING THE ZYTRONIC PROJECTED CAPACITIVE X-Y
CONTROLLER TOUCHSCREEN DRIVER SOFTWARE
This section of the manual describes the step-by-step process to install the Zytronic Projected
Capacitive X-Y Controller Touchscreen Driver software UPDD onto your computer.
Note: Before installing the Zytronic Projected Capacitive X-Y Controller Touchscreen Driver
UPDD Software ensure that the Zytronic Projected Capacitive X-Y Controller Touchscreen is
NOT
connected to your PC.
3.1 Zytronic Projected Capacitive X-Y Controller Touchscreen Driver Software – Universal
Point Device Driver (UPDD)
Before installing the Driver software you will need to download the latest software and manual from
the Zytronic website (http://www.zytronic.co.uk/downloads.htm
). The Driver software installation
described in this manual is for use with the Zytronic Projected Capacitive X-Y Controller Touchscreen
Serial and USB product only.
3.2 Driver Software Installation
To install the Driver Software carry out the following:
1. Log on to the Zytronic website (http://www.zytronic.co.uk/downloads.htm
) and download the
latest Zytronic Projected Capacitive X-Y Controller Touchscreen Driver UPDD software zip
file onto to your PC Windows desktop.
2. Un-zip the Driver files onto your Windows desktop.
3. The Un-zipped file is called Setpup.exe.
4. Using your mouse double click onto the Setpup.exe icon.
5. Having double clicked onto the Setpup.exe file the UPDD Install page will be displayed, as
illustrated in Figure 14. This page gives the user the following selectable options:
a. Install Zytronic, x-y, Serial Controller.
b. Install Zytronic, x-y, USB Controller.
6. At this point the user needs to select the correct controller, either Serial or USB, to be used.
7. If the Serial option is selected, a further drop down menu appears asking the user to specify
which Com port the touchscreen is to be connected to, as shown in Figure 15. It’s important
that you ensure the correct Com port is selected.
8. Having selected the desired controller to be used now click on the Install button located in the
bottom right of the install window.
9. The UPDD driver will be installed.
10. After installation has been completed, the Successful installation page window will be
displayed, as shown in Figure 16.
