Touchscreen User Manual – Issue 1
Zytronic X-Y Controller (Serial and USB) 12
Figure 5: Serial RS232 Touchscreen controller PCB card
Figure 6: USB Touchscreen controller PCB card
Sensor Flexi Tail ZIF
connector interface
Serial Connector Interface
(Molex Connector)
Grounding/Fixing
Holes
Grounding/Fixing
Holes
USB Mini B Connector
Interface
Grounding/Fixing
Holes
Grounding/Fixing
Holes
Sensor Flexi Tail ZIF
connector interface
Power and Operation
LED’s
Power and Operation
LED’s
