Page #91 background image
2N TELEKOMUNIKACE a.s., www.2n.cz 91/104
2 N ® IP Force/Safety
Outputs
– relay output on basic unitrelay1
active digital output on basic unit (for board version 555v3 and higher, output1
active digital output is connected with relay output 1 in 555v2 boards)
– relay output on additional switch (if installed)relay2
– active digital output on additional switch (if installed)output2
– relay output on card reader (if installed)cr_relay1
– active digital output on card reader (if installed)cr_output1
– red LED indicator on card reader (if installed)led_secured
– orange LED indicator of ringing (for models with pictograms only)led_ringing
blue LED indicator of connected call (for models with led_connected
pictograms only)
green LED indicator of door opening (for models with pictograms led_door
only)
– first button backlight at Safetyled_key1
– second button backlight at Safetyled_key2
– third button backlight at Safetyled_key3
Inputs
– tamper switch (if installed)tamper
– digit input 1 on card reader (if installed)cr_input1
– digital input 2 on card reader (if installed)cr_input2
