2N IP Solo - Additional Power Supplies; Two-Wire Connection

Installation manual 2N® IP Solo
21 / 74
•
•
•
•
•
•
•
Part No.91341481E
Axis Part No. 02520-001
Stabilised 12 V / 2 A power supply needs to be used where no
PoE is available.
Part No.932928
12 V transformer
For 230 V mains voltage.
For external power supply of the lock with 12 V AC voltage.
Two-Wire Connection
2N Part No. 9159014EU/
UK
2N Part No. 9159014US
Axis Part No. 01404-001
2N
®
2Wire
(set of 2 adapters and power source for EU/US/UK)
The 2N
®
2Wire converter allows you to use the existing wiring
(2 wires) from your original door bell or door intercom to
connect any IP device. No configuration is necessary, all you
need is one 2N
®
2Wire unit at each end of the cable and a
power source connected to at least one of these units.
The 2N
®
2Wire unit then providesPoEpower not only to the
second converter, but also to all the other connected IP end
devices.
