Installation manual 2N® IP Solo
39 / 74
PoE Power Supply
2N
®
IP Solois compatible with the PoE 802.3af (Class 0–12,95 W) technology and can be fed
directly from the LAN via the compatible network elements. If your LAN does not support this
technology, insert a PoE injector, Part No. 91378100, between2N
®
IP Soloand the nearest
network element.
LAN Connection
2N
®
IP Solois connected to the Local Area Network (LAN) via the UTP/STP cable (Cat 5e or
higher) terminated with an RJ-45 (LAN) connector. As the device is equipped with the Auto-MDIX
function, both the straight and crossed cable can be used.
Basic Unit with Camera (HW version 3) Basic Unit without Camera (HW
version 3)
12 V mA W mA W
At relax 200 2.4 200 1.8
Infrared illumination 158 1.9 – –
LED – call 7 0.08 7 0.8
LED – ringing 5 0.06 5 0.06
LED – lock 4 0.048 4 0.048
LED – allowed access 5 0.048 5 0.048
Button backlight 4 0.048 4 0.048
Name tag backlight 4 0.048 4 0.048
Unit backlight 14 0.168 14 0.168
•
•
Caution
We recommend the use of a LAN surge protection.
We recommend the use of a shielded SSTP Ethernet cable with a shielded RJ-45
connector connected to the switch (with the grounding option) via the same
shielded connector. This makes the device perfectly grounded.

