2N IP Style User Manual

2N TELEKOMUNIKACE a.s., www.2n.cz 11/105
Extending Modules
Part No. 9155084
2N IP Verso
®
– 125 kHz, secured 13.56 MHz,
NFC/HCE Bluetooth & RFID card reader
The card reader module provides access
control via contactless cards or key fobs. The
module also supports the 13.56 MHz cards and
other carriers of the following standards:
125 kHz
EM4xxx
13.56 MHz
ISO14443A (Mifare, DESFire)
PicoPass (HID iClass)
FeliCa
ST SR(IX)
2N Mobile Key
®
HID SE (Seos, iClass SE, Mifare
SE)
Part No. 9137422E
2N IP - External Bluetooth reader (USB interface)
®
An external Bluetooth reader connected via
USB to your computer.
It can be used for pairing new users who want
to use their smartphones with the 2N Mobile
®
application for access to controlled areas.Key
A USB driver is required for the external reader
to work properly.

2N IP Style Specifications

General

Tamper Switch	Yes
Power Supply	12V DC
Ingress Protection	IP65
Inputs	2
Operating Voltage	12V DC
Speaker Impedance	8 Ohm
